PIVOT C24 - aluminum pivot front door with vertical windows

SKU
PIVOT C24
Rating:
100 % of 100
AVAILABLE
CA$13,610.00

The price includes TAX & shipping

Click here to select the configuration

Doors are manufactured after the order has been placed through the website.
Production time for our doors:
door named PIVOT (aluminum) - production takes 6 weeks

Size pivot door with frame:
Width from: 55.1" to 78"
Height from: 78.7" to 116"

Available door colors:
anthracite, white, black, silver gray, red, blue, yellow, brown, green, walnut, wenge, golden oak, mahogany, custom from RAL palette

You can order this door model in a smaller size. View LIM C24

Technical specifications

Air tightness max. test pressure 4 (600 Pa)
Water tightness 4A (150 Pa)
Wind load resistance C3 (1200 Pa)
Burglar resistance RC2/WK2
Thermal insulation R-Value 6.8

The door set includes:

- Aluminum pivot door and the door frame;
- the door handle;
- FUHR 835 4-point lock
- low threshold door
- Standard lock insert with 5 keys.

Full door information

The door is already mounted onto the frame (prehung door), which saves you all the work. The door is completely ready for installation.

The picture showing how to take the measurement. Click here
The installation space between the frame and the wall can be between 0.2" to 0.8" on each side

Frequently Asked Questions: click here to check

-
+
CA$13,610.00

The price includes TAX & shipping

We found other products you might like!

Technical specifications:

  • frame depth door: 78 mm / 3.1",
  • Depth Vent: 78 mm / 3.1"
  • Air tightness: Class 4 (600Pa)
  • Wind load resistance: Class C3 (1200Pa)
  • Water tightness: Class 4A (150Pa)
  • Opening & closing resistance: Class 5
  • standard glazing package 4th/16Ar/4/16Ar/4th [Ug=0,6]*
  • Burglar resistance: RC2
  • Thermal insulation: Ud = 0.83 W/K*m2 / R-Value 6.8

The door set includes:

  • Aluminium pivot door and the door frame;
  • the door handle;
  • FUHR 833 3-point lock
  • low threshold door
  • standard lock insert with 5 keys.
Pivot door in full glass version

Pivot door with an aluminum overlay panel

Glazing

The glass in our doors are triple-pane windows. All panes are connected with spacer frames. Two of them are covered with Low-E coatings that provide natural light while helping to limit heat gain and thermal energy loss. It is also possible to choose P4 anti-burglary glass or safety glass VSG 33.1

standard glazing package 4th/16Ar/4/16Ar/4th

safety glass 33.1//4//4

P4 anti-burglary

Types of glazing

There is a wide range of glass options. In our offer one will find energy-saving, sound-absorbing, safety, anti-burglary and sunscreen windows. The most popular ones are milk glass, decorative or mirror glass as well as bronze reflex glass.

Colours

Colours can emphasise the shape of aluminium joinery and provide it with individual character and genuine appearance. All aluminium systems offered are available in two colour palettes – RAL and DECORAL.
RAL Basic colour palette.

Fiery red or maybe a delicate blue? The RAL K5 Classic colour palette will allow you to choose the colour of the door perfectly suited to your requirements!



RAL 1003

RAL 2004

RAL 3020

RAL 5002

RAL 6005

RAL 6021

RAL 7016

RAL 7039

RAL 7040

RAL 9016

RAL 9005

RAL 9007

Touch line handles

Touch line handles are made of the highest quality materials. They are available in anodized versions (covered with a layer of aluminum oxide) and powder coated in the entire range of the RAL palette (400 + colors).

Sublime, timeless design makes these elegant handles emphasize the appearance of each door.

T-bar - long vertical handle or normal handle:

Stainless steel door handles are designed for one or two-sided use for external doors.
The innovative mounting system enables quick and easy installation of the door handle. Our offer includes many handrails:




Q10
T-bar with a square section of 40×40 mm / 1.6"x1.6".
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9".

Q45
T-bar at an angle of 45 degrees with a square section of 40 × 40 mm / 1.6"x1.6"
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9".

P10
T-bar with a round cross-section ⌀ 40 mm / 1.6" .
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9"

P45
T-bar at an angle of 45 degrees with a round cross-section ⌀ 40 mm / 1.6".
Available in lengths: 1200 / 47.2", 1600 / 63", 1800 mm / 70.9".

Z18
Black, designer handle.
Available in length 480 mm / 18.9".

Z20
Black T-bar with an interesting design
Available in length 498 mm / 19.6".

Z32
Black T-bar with an interesting curve that can also be used for all-glass doors
Available in length 499 mm / 19.6".

Z24
Black, oval handle
Width 450 mm/ 17.7"

Z52
T-bar round z52 copper
⌀ 198 mm / 7.8"

Z53
T-bar round z53 silvershine
⌀ 198 mm / 7.8"

Z54
T-bar round z54 slivergalaxy
⌀ 198 mm / 7.8"

Recessed
T-bar recessed
Available in lengths: 1200 mm / 47.2" and 1800 mm / 70.9"

Multipoint locking system Fuhr 835

Automatic multipoint locking system with a deadlocking latch.

Fuhr lock is the excellent locking system that guarantees comfort as well as security. The lock function ensures reliable, automatic locking and protection against uninvited guests. All you have to do is pull the door closed.

After closing the door, our three-point locking system protects against door warping, offering long-lasting seal tightness and a thermal efficiency.



The most important features:

Increased security – due to automatic locking there is no need for conventional locking with using a key.

Convenient opening – Effortless key operation thanks to two-stage opening sequence from the outside or using the lever handle from the inside.

Increased heat insulation – The multipoint locking system prevents the door from warping to ensure consistent seal tightness around the whole door leaf/slab.

Reliability and durability – long service life is guaranteed and has been tested with over 200,000 cycles.



Locking the lock:
  • After closing the door, the latch in the main lock and additional bolts automatically lock the door.
  • A single turn of the key causes the bolt of the main lock to be activated.
Unlocking the lock:
  • Turning the key once withdraws both lock and bolts. Pressing the handle down causes the latch to be automatically released and allows to open the door.



Class A insert 6.D.C cylinder with keys

Durability: 100 000 cycles
Security rating: Class 6 the highest
Attack resistance: Class D the highest
Burglar resistance: Class C the highest

Certified, cylindrical, profiled 9-ratchet insert (two rows of latches). Innovative anti-drill and anti-picking protection. Inserts resistant to bumping. 5 keys included, key code card.

Write Your Own Review
You're reviewing:PIVOT C24 - aluminum pivot front door with vertical windows
Your Rating

The PIVOT C24 aluminum pivot front door with vertical windows is a remarkable fusion of contemporary design, superior craftsmanship, and innovative engineering, designed to transform the entrance of any residential or commercial property. This door exemplifies modern architectural trends by combining sleek lines, durable materials, and functional elegance to create a statement piece that enhances both curb appeal and interior ambiance.

At the heart of the PIVOT C24 is its distinctive pivot mechanism, which sets it apart from traditional side-hinged doors. Instead of swinging from hinges along the edge, the door rotates around a central or offset pivot point, allowing for a smooth, balanced motion that feels both effortless and visually captivating. This pivot action not only provides a dramatic architectural element but also allows for wider openings, making it ideal for spaces that require seamless indoor-outdoor transitions or accessibility for larger items.

Crafted from high-quality aluminum, the PIVOT C24 is engineered to withstand the rigors of daily use and exposure to the elements. Aluminum’s inherent resistance to corrosion, warping, and rust ensures longevity and minimal maintenance, offering homeowners and designers a reliable entrance solution that retains its pristine appearance over time. The material’s lightweight nature also contributes to the door’s smooth pivot operation, enhancing user experience without compromising on strength or security.

One of the standout features of the PIVOT C24 is the incorporation of vertical windows integrated thoughtfully along the door’s height. These slim, elongated glass panels introduce an abundance of natural light into the interior space, brightening entryways and creating an inviting atmosphere without sacrificing privacy. The glazing options typically include double or triple-pane glass with low-emissivity coatings, providing excellent thermal insulation and soundproofing. This ensures the door not only enhances aesthetic appeal but also contributes to energy efficiency and comfort within the home or building.

Customization options for the PIVOT C24 are extensive, allowing you to tailor the door to perfectly suit your architectural style and personal preferences. The aluminum frame can be finished in a variety of contemporary colours and textures through a durable powder-coating process that resists fading, scratching, and weather damage. Additionally, a selection of hardware finishes and designs, such as minimalist handles or bold statement pieces, further personalize the door’s look and functionality.

Security is a paramount consideration in the design of the PIVOT C24. The door features reinforced frames and advanced locking mechanisms, providing robust protection against forced entry without detracting from its sleek appearance. The precision-engineered pivot hardware ensures stable and reliable operation, maintaining perfect balance and smooth movement even with frequent use.

In summary, the PIVOT C24 aluminum pivot front door with vertical windows offers an exquisite blend of form and function. Its innovative pivot design, combined with durable aluminum construction and elegant vertical glazing, makes it an ideal choice for those seeking to make a bold architectural statement while enjoying enhanced natural light, energy efficiency, and security. Whether for a modern home or a sophisticated commercial space, the PIVOT C24 elevates the entrance experience, marrying contemporary style with lasting performance.
